AD9226 ADC Module 65M Acquisition Analog-to-Digital Converter FPGA Development Board Supporting
Product details
| Management number | 222662387 | Release Date | 2026/05/04 | List Price | $21.72 | Model Number | 222662387 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Specification: Module model: AD9226 Module type: Analog to digital conversion module Sampling rate: 65M SPS (MAX) ADC resolution bits: 12 bits Input voltage range: 10VPP (±5V) Power supply: DC5V Provide routines: Verilog FPGA source code Example platform: QuartusII EP4CE15F17C8 Communication protocol: 13-bit parallel SPI Communication signal level: 3.3V Input impedance: 50 ohms Number of input channels: 1 channel Input interface: SMA tuner/XH2.54 hole Reference voltage: internal 2V -3dB analog bandwidth: 320MHz Output mode: Parallel data Module features: High-speed ADC acquisition Module application: High-speed signal acquisition Module weight:16g Module size: 54X37X23mm Module interface type: 13-bit data SPI parallel Packing: 1*AD9226 Analog to Digital Conversion Module
- Module type: Analog to digital conversion module
- Sampling rate: 65M SPS (MAX)
- ADC resolution bits: 12 bits
- Input voltage range: 10VPP (±5V)
- Power supply: DC5V
| Model | KWKJ-AD9226 |
|---|---|
| Interface | Coaxial |
| Brand Name | Q-BAIHE |
| Item Weight | 0.5 Kilograms |
| Part Number | KWKJ-AD9226 |
| Manufacturer | Q-BAIHE |
| Mounting Type | PCB Mount |
| Number of Pins | 15 |
| Number of Channels | 1 |
| Item Dimensions L x W | 2.13"L x 1.46"W |
| Maximum Supply Voltage | 5 Volts |
| Minimum Supply Voltage | 5 Volts (DC) |
